The MP-HD-42ARC is a 4×2 HDMI 2.0 presentation switcher with matrix outputs. The switcher consists of four HDMI inputs, two HDMI matrix outputs and full HDMI 2.0 support The product offers SPDIF and 3.5mm output for dual HDMI OUT audio extraction and dual HDMI OUT ARC along with 4K to 1080p down scaling functionality. It features a wide range of control flexibility via Web, RS232, IR and smart EDID management
| Video Input | |
| Video Input | (4) HDMI |
| Video Input Connector | (4) Type-A female HDMI |
| Video Input Resolution | Up to 4K@60Hz 4:4:4 8bit |
| HDMI Audio Format | Supports Dolby Atmos, Dolby TrueHD, Dolby Digital Plus, Dolby Digital, DTS-X, DTS-HD Master Audio, DTS 5.1, 2 – 8Ch PCM 32-192KHz 16-24 bits; 2 – 8Ch PCM 32-192kHz 16-24 bits. |
| HDMI Input Cable | 4K@60Hz 4:4:4 3 meters , other 5 meters |
| Video Output | |
| Video Output | (2) HDMI |
| Video Output Connector | (2) Type A Female HDMI |
| Video Output Resolution | OUT A: Up to 4K@60Hz 4:4:4 8bit, HDR10, Dolby Vision, supports color space 4:2:2/4:2:0 to 4:4:4, 4K to 1080p down-scaling |
| OUT B: Up to 4K@60Hz 4:4:4 8bit, HDR, Dolby Vision | |
| HDMI Output Cable | ≤ 5 meters |
| HDMI Version | Up to 2.0 |
| HDCP Version | Up to 2.2 |
| Digital SPDIF Audio Output | |
| Audio Output | (1) Digital SPDIF audio |
| Audio Output Connector | (1) Toslink connector |
| Output Level | ±0.05dBFS |
| Frequency Response | 20Hz~20KHz, ±1dB |
| THD+N | < 0.05%, 20Hz~20KHz bandwidth, 1KHz sine at 0dBFS level (or max level) |
| SNR | > 90dB, 20Hz~20KHz bandwidth |
| Crosstalk isolation | < -70dB, 10KHz sine at 0dBFS level (or max level before clipping) |
| Noise Level | -90dB |
| Unbalanced analog Audio Output | |
| Audio Output | (1) Unbalanced analog audio |
| Audio Output Connector | (1) 3.5mm jack |
| Frequency Response | 20Hz~20KHz, ±1dB |
| Max output level | 2.0Vrms ± 0.5dB. 2V=16dB headroom above-10dBV (316 mV) nominal consumer line level signal |
| THD+N | < 0.05%, 20Hz~20KHz bandwidth, 1KHz sine at 0dBFS level (or max level) |
| SNR | > 80dB, 20Hz~20KHz bandwidth |
| Crosstalk isolation | < -80dB, 10KHz sine at 0dBFS level (or max level before clipping) |
| L-R level deviation | < 0.05dB, 1KHz sine at 0dBFS level (or max level before clipping) |
| Output load capability | 1Kohm and higher (supports 10x paralleled 10Kohm loads) |
| Noise Level | -80dB |
| Control Part | |
| Control Port | (1) EDID Switch, (1) FW, (1) RS232, (1) IR IN, (1) TCP/IP |
| Control Connector | (1) 4-pin DIP Switch, (1) Micro USB, (1) 3-pin terminal block, (1) 3.5mm jack, (1) RJ45 |
| General | |
| Bandwidth | 18Gbps |
| Operation Temperature | -5 ~ +55 |
| Storage Temperature | -25 ~ +70 |
| Relative Humidity | 10%-90% |
| External Power Supply | Input: AC 100~240V, 50/60Hz; Output: 12V DC 1A |
| Power Consumption | 7.5W (Max) |
| Dimension (W*H*D) | 200mm x 28.5mm x 100mm |
| Net Weight | 605g |
