LARGE ROOMS, UNLIMITED POSSIBILITIES
Supplying room-filling audio to large meeting rooms might be a challenge for some conference phones. Not for Trio 8800. Specially tuned mics catch every word in a 20-foot range. Wi-Fi, USB and Bluetooth® connectivity is built in. And video conferencing and content sharing can be easily added, ensuring future-proof flexibility. Get ready to transform your large spaces into powerhouses for collaboration.
KEY FEATURES:
- POLY SIGNATURE AUDIO: For a conference call that gets results, Poly audio ensures every inflection is heard, without the distracting background noise. Hear their reaction with up to 22 kHz of rich, full sound.
- ALL KINDS OF CONNECTIONS: Collaborate using audio, video, content or all three. The Trio 8800 helps teams make decisions faster through a variety of meeting options.
- HYBRID REGISTRATION: Connect to the platform you like best. Connect to one or multiple leading SIP and Cloud Conferencing Services at the same time—no need to choose just one.
- ONE-TOUCH JOIN: Join a meeting in seconds with a single touch of a button and keep your meeting time productive.
- SIMPLE MEETING CONTROL: Conveniently placed illuminated mute indicators on each leg of the device are within easy reach—so everyone can clearly see when the mic is live and when it’s muted.
- BLUETOOTH®/NFC: Easily connect your mobile device or laptop via Bluetooth®/NFC or USB, and use Trio as the speakerphone to enhance the audio experience of personal devices.
- NETWORK CONNECTIVITY: Supports IP Standards based communication, PoE/PoE+, Wi-Fi (2.4/5GHz). BYOD connectivity via Bluetooth, & USB mode.
- 5” COLOR TOUCH DISPLAY: The 5″ color touch display puts familiar, easy-to-use icons and user controls at your fingertips for quick meeting starts —and calendar integration ensures your meetings get started in seconds with one-touch-join.
A BIG IDEA FOR BIG IDEAS
The talk around the table says the team’s got a big idea. But do people dialed in to the room know that? Whether it’s by audio, video, or content sharing, give your teams the ability to clearly express their ideas with a Poly Trio. It delivers many best-of-breed capabilities from a single, sleek device. People can connect with a touch, on almost any platform, to get amazing sound on a phone optimized for their room size.
A BIG IDEA FOR BIG IDEAS
Whether it’s via audio, video, or content sharing, Poly Trio conference phones give your teams the ability to clearly express and exchange ideas.
Specifications
| Category | Feature |
|---|---|
| User Interface Features | |
| Touch Screen | Gesture-based, multitouch-capable capacitive touch screen |
| Display | 5-inch color LCD (720 x 1280 pixels), 9:16 aspect ratio |
| Keyboard | On-screen virtual keyboard |
| USB Ports | 1x USB 2.0 Type A-compliant port (USB battery charging BC1.2 compliant), 1x USB 2.0 Micro-B device port for USB audio device |
| Wireless | Integrated Bluetooth 4.0 and NFC |
| Indicators | 3 multicolored capacitive-touch mute indicators |
| Character Support | Unicode UTF-8-character support |
| Localization | Arabic, Chinese, Danish, Dutch, English (Canada/US/UK), French, German, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, Slovenian, Spanish, Swedish |
| Audio Features | |
| Microphones | 3 cardioid microphones |
| Loudspeaker | |
| Frequency | 100-22,000 Hz |
| Volume | 92 dB at 0.5-m peak volume |
| Microphone Pickup Range | 6 m / 20 ft |
| Supported Codecs | G.711 (A-law and μ-law), G.719, G.722, G722.1, G722.1C, G.729AB, Poly Siren 7, Siren 14, iLBC (3.33Kbps and 15.2Kbps), Opus (8Kbps – 24Kbps), SILK |
| Additional Features | Poly Acoustic Clarity technology, Poly NoiseBlock, Voice activity detection, Comfort noise generation, DTMF tone generation (RFC 2833 and in-band), Bluetooth device pairing (HFP/AD2P), Low-delay audio packet transmission, Adaptive jitter buffers, Packet loss concealment |
| Video Conferencing and Content Sharing Options | Compatible with Trio Visual+ & VisualPro codecs with supported cameras |
| Call Handling Features | |
| Call Capacity | Up to three lines (max. one Skype for Business and Microsoft Teams) |
| Call Features | Shared call/bridged line appearance, Distinctive incoming call treatment/call waiting, Call timer and call waiting, Call transfer, hold, divert (forward), pickup, Called, calling, connected-party information, One-touch speed dial and meeting join, Local five-way audio conferencing, Daisy-chain up to four Trios total, Do-not-disturb function, Local configurable digit map/dial plan, Corporate directory access using LDAP, Visual conference management |
| Network and Provisioning | |
| Protocols | Open SIP, Skype for Business certified, Microsoft Teams certified, Zoom certified, IETF SIP (RFC 3261 and companion RFCs) |
| Ethernet | Two-port gigabit Ethernet switch, 10/100/1000Base-TX across LAN and 2nd port |
| 2nd Port | Supports IEEE 802.3af PSE |
| Wi-Fi | Wi-Fi network connectivity, 2.4–2.4835 GHz (802.11b, 802.11g, 802.11n HT-20), 5.15–5.825 GHz (802.11a, 802.11n, HT-20, 802.11n HT-40) |
| Configuration | Manual or dynamic host configuration protocol (DHCP) network setup, Time and date synchronization using SNTP, FTP/TFTP/HTTP/HTTPS server-based central provisioning, RealPresence Resource Manager (v. 10.1 or above) based provisioning, Poly Zero Touch Provisioning, Provisioning and call server redundancy support, RealPresence Resource Manager (v 10.1 or above) based provisioning, PDMS-E, PDMS-SP |
| QoS Support | IEEE 802.1p/Q tagging (VLAN), layer 3 TOS, and DSCP, WMM (Wi-Fi multimedia), VLAN – CDP, DHCP VLAN discovery, LLDP-MED for VLAN discovery |
| Security | |
| Authentication | 802.1X authentication and EAPOL |
| Encryption | Media encryption via SRTP, Transport layer security (TLS) v 1.2, Encrypted configuration files, Digest authentication, Password login, Support for URL syntax with password for boot server address, HTTPS secure provisioning, Support for signed software executables |
| Wi-Fi Encryption | WEP, WPA-Personal, WPA2-Personal, WPA2-Enterprise with 802.1X (EAP-TLS, PEAP-MSCHAPv2) |
| Power | |
| LAN IN | Built-in auto-sensing IEEE 802.3at. PoE Device (Class 4), requires full Class 4 power input on LAN IN for operation, Backward compatibility with IEEE 802.3af |
| LAN OUT | Built-in auto-sensing IEEE 802.3af power sourcing equipment, requires full Class 4 power input on LAN IN for operation |
| Phone Dimensions (L x W x H) | 38.3 x 7.5 x 33.2 cm (15.1 x 2.9 x 13.1 in) |
| Unit Weight | 950 g / 2.1 lbs |
| Box Dimensions (L x W x H) | 48.3 x 11.5 x 39.4 cm (19 x 4.5 x 15.5 in) |
| Box Weight | 1970 g / 4.3 lbs |
| Package Includes | |
| Items | Trio 8800 Phone Console (open SIP): 2200-66070-001, 7.6-m/25-foot network cable CAT 5e, 2-m/6.5-foot USB 2.0 cable |
| Optional Accessories | |
| Accessories | Poly Trio Expansion Microphones (2200-65790-001), Power kit incl. ext. single-port gigabit midspan, 802.3at Type 2 compliant, local power cord and network cable (7200-23490-xxx) |
| Warranty | |
| Coverage | 2-year limited hardware replacement warranty against manufacturing defects |
